Key Technical Features
High-Impact Crushing Power: Equipped with heavy-duty manganese steel hammers that deliver powerful impact to crush loose scrap into high-density, clean fragments.
Customized Output Size: Integrated with adjustable bottom grates (screens), allowing you to precisely control the final output size for different recycling requirements.
Built for Durability: Features a reinforced thick-wall chassis and wear-resistant liners, designed to withstand continuous operation in the harshest recycling environments.
Smart Safety & Control: Driven by a Siemens PLC system with automatic overload protection, ensuring stable performance and minimizing machine downtime.
Simplified Maintenance: The hydraulic-assisted opening system provides quick and safe access to the rotor and internal parts for fast hammer replacement.
 |
Why Choose SOYU?
Robust Build: The chassis is constructed from thick, wear-resistant steel plates to withstand extreme vibrations and impacts.
Energy Efficiency: Optimized rotor design and heavy flywheels utilize inertia to reduce energy consumption during peak loads.
CE Compliance: Fully compliant with international safety standards, including emergency stop protocols and safety interlocks.
|
Model |
TLJ80-55 |
TLJ80-75 |
TLJ80-90 |
|
Motor power（kw） |
55 |
75 |
90 |
|
Screen diameter（mm） |
40/50/60（optional） |
40/50/60（optional） |
40/50/60（optional） |
|
DimensionL*W*H（mm） |
2710*1950*1900 |
2710*1950*1900 |
2710*1950*1900 |
|
Weight（kg） |
6000 |
6100 |
6200 |
|
Model |
TLJ100-160 |
TLJ100-200 |
|
Motor power（kw） |
160 |
200 |
|
Screen diameter（mm） |
40/50/60 |
40/50/60 |
|
DimensionL*W*H（mm） |
2710*1950*1900 |
3700*2500*2450 |
|
Weight（kg） |
13500 |
14500 |
|
Model |
TLJ130-315 |
TLJ130-450 |
|
Motor power（kw） |
315 |
450 |
|
Screen diameter（mm） |
60/80/100（optional） |
60/80/100（optional） |
|
Number of hammer heads（pcs） |
24 |
24 |
|
DimensionL*W*H（mm） |
3900*3700*3770 |
3900*3700*3770 |
|
Weight（kg） |
22000 |
28000 |
